Collector for 4 poles powerail
型號：MCCB56
認證：
25A&80A overhead crane bridge crane current collector
Type Weight(KG) Poles Power Rating(V) Order No 56JD-4/25 0.49 4
25A 561001 56JD-4/40 0.52 40A 561002 56JD-4/60 0.99 60A 561003 56JD-4/80 1.23 80A 561004 56JD-4/40 0.85 3 80A 561005 Descriptions:
1.This type collectors are used for 35A~170A HFP56 Powerail Enclosed Conductor Systems.
2.Max speed 150m/min,for powerails with sealing strip is up to 100m/min.
3.Copper cross section 2.5mm2 per core for 25A, 4.0mm2 per core for 40A, 6.0mm2 per core for 60A.
4.Trolley connecting cable 0.8m long, longer cable available.
5.The HFP56 System is a powerail, protected from contact, for indoor and outdoor plants.They are conductor lines in a rigid green PVC housing.
6.Type HFP56:not include sealing strip, with factory-mounted flat copper band and bolted-operated plug connectors from 35A to 170A.
